TS 3000 EC
T-Stop guide rail TS 3000/ 5000 * With opening restrictor and lever
- Easy to replace with the standard guide rail
- Saves time as no floor mounted door stopper needs to be installed
- With screwed sliding block
- Pivot bearing T-Stop
With opening restrictor and lever
Application Areas
- Single leaf doors
- Installation on hinge side
- Right and left single-action doors
- For opening restriction without door stopper
Technical data
| T-Stop guide rail TS 3000/ 5000 | |
| Length | 452.5 mm |
| Width | 33 mm |
| Height | 30 mm |
| Opening restrictor integrated | Yes |
| Hold-open device | Optional |
Downloads
Variants & Accessories
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
