TSA 355 Manual door
TSA 355 Manual door * Manual revolving door system for three- or four-leaf doors
- Customised choice of diameter, passage height and surfaces
- Extensive equipment options
- Simple installation of the door system without lifting tools
- Fast commissioning thanks to pre-cabled and configured sensors
Note: The product listed may not be available in your country. Please contact your GEZE contact person or send us an e-mail.
Application Areas
- Three- and four-leaf door systems
- Interior and exterior doors with high access frequency
- Representative building entrances with large incidence of light
- Façades with slim mullion-transom constructions
- Diameters from 1740 to 3540 mm possible
Technical data
| TSA 355 Manual door | |
| Manual operation | Yes |
| With speed limiter (optional) | Yes |
| Break-out function (BO) | Yes |
| Inner diameter (min.) | 1740 mm |
| Inner diameter (max.) | 3540 mm |
| For 3-leaf door systems | Yes |
| For 4-leaf door systems | Yes |
| Clear passage height | 3000 mm |
| Canopy height (min.) | 200 mm |
| Side elements version | 8 mm LSG |
| Version of roof structure | optical sheet metal covering, waterproof roof with waterspout |
| Illumination | with roof variant, according to customer wishes |
| Floor covering | Entrance mat, Entrance mat according to customer wishes |
| Hot-air curtain system | hot water air curtain, Electric air curtain, possible, depends on the ceiling construction |
| Night-time closer layout | Outside |
| Night-time closer type | Manual |
| Night-time closer design | 8 mm LSG |
| Lock | Manual |
| Door handles horizontal or vertical | Yes |
| Floor ring | Yes |
Downloads
TSA 355
LABELLING OBLIGATION: © GEZE GmbH
* Notice about the products displayed
The products mentioned above may vary in form, type, characteristics and function (design, dimensions, availability, approvals, standards etc.) depending on the country. For questions please contact your GEZE contact person or send us an E-Mail .
